Display of remote control
 Fig. 4
Pos. Symbol Explanation
1 Operating function: Follow Me function is active
(Follow Me); temperature measurement at the
remote control.
Infographic: wireless control function
Infographic: battery status
2 Operating mode: automatic mode
Operating mode: cooling mode
Operating mode: dehumidification mode
Operating mode: heating mode
Operating mode: Fan Mode
3 Value display: shows the set temperature, fan speed
or (when timer is activated) the timer setting as
standard.
Infographic: transmission indicator; lights up when
the remote control sends a signal to the indoor unit.
Infographic: ON/OFF timer active.
Value display: shows the current fan speed. There are
several output stages (bars) and the AUTO setting for
automatic control
4 Infographic: automatic vertical swing function active
(up/down). Alternative display of current position of
horizontal louvre.
Infographic: Turbo cool/Turbo heat is active.
Table 46 Symbols in the display
3.4

Using the remote control

The signal range is 8 m. If objects are in the way or certain fluorescent
lamps are used in the same room this can affect transmission of the signal.
▶ Point the remote control towards the signal receiver window of the
device and press the desired key.
The device emits a beep when it receives a signal.
NOTICE
The remote control may be permanently prevented from working correctly.
▶ Do not expose the remote control to direct sunlight.
▶ Do not leave the remote control near a heating appliance.
▶ Protect the remote control from moisture and impacts.
3.5

Setting main operating mode

Switching the appliance on/off
▶ Press the K key to switch the device on or off:
The unit starts in the set operating mode or switches off. To protect
the unit it can only be switched back on after some time has passed.
Settings can also be made when the appliance is switched off.
The device saves the settings, and also retains them in the event of a
power failure.
After it has been switched off, the unit remains in standby mode.
Climate 5000i M – 6721849824 (2022/11)
Following a power failure the unit restarts automatically. This can lead to
conflicting readings on the displays which are resolved automatically
during operation.
Automatic mode
In automatic mode, the unit switches automatically between heating,
cooling, fan and dehumidification mode, depending on the set
temperature.
▶ Press the Mode key repeatedly until
▶ Select the required temperature with the . and / keys.
The fan speed cannot be adjusted in automatic mode.
Cooling mode
▶ Press the Mode key repeatedly until
▶ Press the key until the required air speed is reached.
▶ Select the required temperature with the . and / keys.
Fan (Only) Mode
▶ Press the Mode key repeatedly until
▶ Press the key until the required fan speed is reached. AUTO can
be selected to enable automatic control.
The temperature cannot be adjusted or displayed in fan mode.
Dehumidification mode
▶ Press the Mode key repeatedly until
▶ Set the required temperature with the . and / keys.
The fan speed cannot be adjusted in dehumidification mode.
Heating mode
▶ Press and hold the Mode key until
▶ Set the required temperature with the . and / keys.
▶ Press the key until the required air speed is reached.
If the outside temperature is very low, the heating capacity of the air
conditioning system may not be sufficient. We recommend connecting
additional heat sources.
3.6

Louvre position memory

When the appliance restarts after a power failure, the louvres
automatically revert to the position that was previously set. Press the
Manual operation key on the indoor unit to restore the setting of the
louvres.
Following adjustment, the angle of the horizontal louvres should not be
too small, as otherwise condensate may form and drip into the
appliance.
Operation
appears on the display.
appears on the display.
appears on the display.
appears on the display.
appears on the display.
