4.5 Mopping module (clean it every time)
1.Remove the mop, pure out the water from water tank.
2.Clean the mop, dry the water tank and mop
4.6 Sensor Cleaning (clean it regularly)
Clean the sensors by soft mop, include:
1. Clean the sensors along the wall on the right.
2. Three anti-dropping sensors at the bottom of the host.
3. Infrared avoidance sensor in the front of the host.
4. Radar avoidance sensor on the top of the host.
5. Electric shock protector and charging base shrapnel at the bottom of the host (please cut of the power during cleaning).
6. Signal transmission area of charging base.
C
M
Y
CM
MY
CY
CMY
K
4.7 Battery
Upgrade firmware using mobile APP. If new firmware is detected, upgrade it according to prompt. The battery level should be ≥50%
during firmware upgrade, so the machine should be placed on the charging base.
4.8 Firmware upgrade
Upgrade firmware using mobile APP. If new firmware is detected, upgrade it according to prompt. The battery level should be ≥50%
during firmware upgrade, so the machine should be placed on the charging base.
4.9 System reset
Take down the dust box, open the rubber plug and press Reset key (refer to page 4). Current map will be lost and timing, WiFi and
personalized settings will be reserved after reset.
Anti-dropping sensor
Charging contact
LDS laser ranging sensor
Anti-collision sensor for radar
Anti-collision sensor
Infrared recharging sensor
Signal emission area
Charging base pins
