11.4 Replacement of ESK+ Mechanism

The instructions in this section are for practitioner use only.
1
Offer up side plate to align slot in spindle (2) with dowel (1)
but do not fit at this stage.
3
ORIENTATION IS IMPORTANT!
Assemble flat sides and lettering (RH,
LH) facing inwards.
6
4
Oscillate during
assembly
7
18
2
Screw spindle to chassis.
5
Re-apply preload
8
with recorded
number of clicks.
Underside
view of
chassis.
938250PK1/1-0421
