Part 1 - Unboxing

Please make sure all the following parts are included. If you are missing any part or have any questions, please email us at
support@sainsmart.com.
(2) Aluminum Profile
1
20 x 40 x 290 mm
(2) Guide Rail
5
Y Axis, Ø10 x 290mm
9 Bakelite Resin Plate B
(2) Aluminum Profile
2
20 x 20 x 360mm
Lead Screw 365mm
6
10 Bakelite Resin Plate C
Aluminum Profile
3
300 x 180mm
Lead Screw 295mm
7
11 Bakelite Resin Plate D
(2) Guide Rail
4
X Axis, Ø10 x 360mm
Bakelite Resin Plate A
8
12 (2) Stepper motor
03
