Genmitsu 3018-PRO Benutzerhandbuch Seite 21

(2) Aluminum Profile
2
20 x 20 x 360mm
6
Lead Screw 365mm
(2) Guide
4 Rail X Axis
Ø10 x 360mm
31
Brass Nut
28
14
X-Z Axis
Assembly
Stepper
12
motor
Coupling &
32
Set Screw
26 (4) Bolt M5 x 16
27 (4) Bolt M3 x 14
19
