USER MANUAL
# DESCRIPTION
75 Anti-proof washer
76 Two groove nut
77 Ball shaft
78 Bead bowl
79 Tri-groove nut
80 Washer
81 Belt Pulley
82 Round Magnetic
83 Belt 360PJ6
84 Spring Washer D6
85 Snap Ring D12
86 Magnetic Board Axle
87 Magnetic Board
88 Magnetic
89 Magnetic Grip
90 Drag spring
91 Crossed pan head screw ST3*10
92 Hex nut M6
93 Hex bolt M6*60
94 Flat washer φ10.5*φ20*2
95 Idle Pulley Spacer Bush
96 Idle Pulley
97 Hex bolt M6*15
98 Inner hex cylinder head screw M6*30
99L Chain Cover L
99R Chain Cover R
100 Electric resistance control wire
101 Crossed pan head screw ST4.2*16
102 Sensor
103 Hole Sealing
104 Flat washer φ6.5*φ16*1.5
105 Hex bolt M6*9
106 Bearing Board
107 Bearing 6001RS
108 Bearing Seat
109 Power line
110 Motor
111 Adapter
QTY. #
1 112 Inertia wheel axle
1 A Inner hex wrench S6
2 B Inner hex wrench S8
2 C Multi-function wrench S13-14-15
1 D Solid wrench 17-19
1
1
1
1
2
2
1
1
4
1
1
5
3
1
1
1
1
4
1
1
1
1
5
1
2
4
6
2
2
2
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
