Disclaimer
Carefully read this entire document and all safety and compliance guidelines provided before use.
Introduction
The DJI
Video Transmitter uses DJI's O3 Pro Video Transmission technology, which offers a
TM
transmission range up to 6 km*, HD video transmission with a bitrate of 40 Mbps, and an end-
to-end latency as low as 100 ms. It supports multiple frequency bands in both Control mode and
Broadcast mode, as well as one transmitter with multiple receivers, when using with the DJI High-
Bright Remote Monitor, meeting the filming requirements of mediums such as movies, TV series,
advertisements, and documentaries.
* Measured with the video transmission system in Control mode in an unobstructed environment free of
interference that is FCC compliant.
Overview
11
10
1. Detachable Antennas
Transmit wireless signal.
2. Linking Status Indicator
Shows the linking status between the receiver and transmitter. Refer to the Linking section for
more information on blinking patterns.
3. Video Status Indicator
Indicates if there is a video source signal input or not. Solid green indicates input while solid
red indicates no input.
4. SDI Output Port
Outputs the video source signal from the transmitter.
5. SDI Input Port
Inputs the signal from the video source to the transmitter.
©
1
2022 DJI All Rights Reserved.
1
9
2
3
4
5
12
6
7
8
9
13
14
15
16
19
17
18
