Specifications

Weight
Dimensions
Operating Frequency
[1]
Transmitter Power (EIRP)
Power Consumption
Power Supply Voltage
Output Voltage
Working Time
[2]
Input Video Format
Output Video Format
Input Audio Format
Output Audio Format
Video Transmission System
Max Bitrate
Latency
Video Coding Format
Max Transmission Distance
Max Communication Bandwidth
Operating Temperature
[1] Due to local regulations, the 5.1/5.2/5.8GHz frequencies are prohibited in some countries and the
5.1/5.2GHz frequencies are only allowed for use indoors in some countries. 5.600-5.650 GHz is not used.
[2] Tested in a room temperature of 25° C (77° F) when powered by a fully charged WB37 Intelligent Battery
and used with the DJI High-Bright Remote Monitor.
©
11
2022 DJI All Rights Reserved.
Approx. 350 g (transmitter only, excl. antennas)
127×97×26 mm (excl. antennas)
2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.250-5.350 GHz,
5.470-5.725 GHz, 5.725-5.850 GHz
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC/SRRC), <14 dBm (CE)
5.1 GHz: <23 dBm (FCC/SRRC/CE/MIC)
5.2 GHz: <30 dBm (FCC), <23 dBm (SRRC/CE/MIC)
5.5 GHz: <30 dBm (FCC), <23 dBm (CE/MIC)
11 W
External Power Input Port: 6-18 V
DC-In Port: 6-18 V
Power Output Port: 6-18 V
3 hours 40 min
3G SDI: YCbCr 4:2:2 10bit
HDMI: RGB 4:4:4
1080p23.98/24/25/29.97/30/50/59.94/60;
1080i50/59.94/60;
720p50/59.94/60
3G SDI: YCbCr 4:2:2 10bit
1080p23.98/24/25/29.97/30/50/59.94/60;
1080i50/59.94/60;
720p50/59.94/60
HDMI embedded
PCM
O3 Pro
40 Mbps
68 ms (1080p 60fps), 100 ms (1080p 24fps)
H.264
6 km (FCC), 4 km (CE/SRRC/MIC)
(unobstructed, free of interference)
40 MHz
-10° to 45° C (14° to 113° F)
