Information About This Document - dormakaba HSW EASY Safe Montageanleitung

dormakaba Montageanleitung
Mounting instructions
1 Information about this
document
EN
1.1 Contents and purpose
This manual describes the proper mounting of the
deadlock with micro switch. Before commencing any
work, personnel must have carefully read through and
understood this manual. Complying with all safety
instructions and action steps provided in this manual
is the basic prerequisite for safe working.
1.2 Target group
dormakaba glass fittings
may only be mounted by qualified personnel who are
specially trained in glazing installation.
1.3 Other applicable documents
The following document should be observed in
addition to these mounting instructions:
• HSW EASY Safe mounting instructions
1.4 Documents storage
This manual must be kept during the service life of the
product and must be passed on to the facility
operator of the unit.
1.5 Abbreviations
DEF Single action end panel
AT Single action panel with offset pivot
1.6 Symbols used
1.6.1 Hazard categories
WARNING
This signal word indicates a possible
hazardous situation which may result in
death or serious injury if ignored.
CAUTION
This signal word indicates a situation of
potential risk, which could lead to minor or
slight injury if not averted.
ATTENTION
This signal word indicates a situation of
potential risk, which could lead to damage
to property or the environment if not
averted.
Riegelschloss mit Mikroschalter
4
Deadlock with micro switch
1.6.2 More symbols
1. 2.
1 2
2 Safety
2.1 Intended use
The deadlock with micro switch, such as the complete
HSW EASY Safe, is only suitable for dry indoor areas.
2.2 Limitations on use
The deadlock with micro switch, such as the complete
HSW EASY Safe, is not suitable for showers, sauna,
bath or salt-water bath applications or areas where
chemicals (e.g. chlorine) are used.
2.3 Basic warnings
WARNING
Danger to life through electric current!
Works on the electrical unit
must only be carried out by qualified
electricians.
• Before starting work on electrical units
and equipment, establish a voltage-
free state and maintain this state while
carrying out the work.
CAUTION
Risk of injury from broken glass during
mounting.
Incorrect mounting can lead to
broken glass and injuries
.
• Store glass on trestles or wooden blocks
and ensure that it cannot fall.
ATTENTION
Risk of damage to glass components
due to contact with hard materials (e.g.
glass, metal, concrete).
The contact may cause conchoidal fractures,
damage the edges and/or break the glass
of the
glass components.
• Damaged glass components should not be
installed – risk of injury.
WN 059794 45532

Information about this document

Step-by-step graphics
Position numbers of components
in graphics
2019-06
