PURELAB® CHORUS 1 - ENGLISH

3.6 Sanitisation Procedure

PURELAB® Chorus LC271 - Liquid Sanitisation - Instructions provide.
PURELAB® Chorus LC272 - Tablet Sanitisation - Instructions provide.
Please take care to ensure your order is the correct consumables items.
4

SELF HELP GUIDELINES

Constant
Blinking
Constant
Blinking
Blinking
Press
(At any time)
Press and hold for 15
seconds
(At any time)
Press Once
(At any time)
Set Temperature Alarm
Set Water Purity Alarm
Chorus 1
Over fill Protection Alarm
Display Lights
White
White
Red
Red
Red / White
Process Button Operation
Start / Stop Modules
process
Enter / Exit
Press process button for fifteen seconds this will enter commissioning
Commissioning
mode. Press once at anytime to pause / resume commissioning mode.
Procedure
Load firmware from
USB Flash devices
Default Alarm Settings
Set default values from firmware file. Adjustable set point using application
service module. Service module is an engineers tool, only an engineer can adjust the settings.
Select to either 30°C, 35°C, 40°C. Default 35°C.
Set default values from firmware file. Adjustable set point using application service
module. Resistivity range select from 1.0MΩ.cm,10.0MΩ.cm or 15.0MΩ.cm.
Feature activates drain valve if water level is greater than maximum and stops water entering the
system to prevent a flood. When alarm is active:V2 energised. If alarm for 5mins, stop module
process. Enter refill cycle on overfill alarm deactivation. Alarm status removed (Reservoir 95%)
Chorus 1 Operator Manual MANU39998 LSC ANR GSC Version 02 3/17 Page 14
Signifying water purity, unit is operating correctly
Consumables are nearing the end of useful life
System needs immediate attention
System in clean cycle (Sanitization / Commissioning)
Software update
Start and stops modules process
To enter or exit commissioning mode / sanitization procedure.
This can be done using the Halo dispenser in 'Main Menu'
Automatically loads system firmware from USB flash device.
Re-start on completion.
This can be done using the Halo dispenser.
Default Alarm point 15.0MΩ.cm.
