PURELAB® CHORUS 1 - ENGLISH
2
YOUR GUIDE TO THE CHORUS
2.1 Life Science - PC1LSCXM2
Purification Pack
Status Light
Warning Light
Process Button
Ultra Filtration
Module
Ultraviolet Lamp
9. COMMS 2
8. Power In 2
7. COMMS 1
6. Power In 1
5. Return
4. Product Outlet
3. Drain
1. Water Inlet
Chorus 1 Operator Manual MANU39998 LSC ANR GSC Version 02 3/17 Page 2
Use a slotted screw driver to release
quarter turn slots on Chorus.
6mm
*Not supplied
