SET - UP
1a
MODULAR STACKING BENCH MOUNTED RESERVOIR ON TOP
PC1LSCXM2 / PC1ANRXM2 / PC1GSCM2
a. Open doors and undo quarter turn
fasteners.
c. Remove bolt and lift the lid.
NB. Please refer to the dispenser Quick Start Guide to combine a dispenser.
WARNING!
ONLY PLACE ONE CHORUS SYSTEM ON TOP OR BELOW THE RESERVOIR.
d. Place the reservoir on top, lining up
with the three points. Screw in allen
head bolt, before replacing front panel.
Remove carefully
b. Remove front panel and undo lid bolt
with an allen key. (6mm AF X FXBOYR301716)
