Grater
IMPORTANT
DO NOT attempt to use this function while grinding, blending or chopping.
1. Cut the food into pieces. Approximately to the size of 20 × 20 × 60 mm so as to be
easily inserted in the opening of the container. Inserted food should not contain
hard parts. Hard parts could cause the motor to stop. If the motor stops, stop the
appliance immediately and unplug it. Remove the entire grater assembly. If the
motor stops automatically, eliminate the cause of the stop. After the motor has
cooled down, it is possible to continue.
2. Switch the appliance on by pressing the speed control button (4) to the speed 5.
3. Place the food in the container exclusively using the stamper.
4. After grinding is completed, turn the speed control button (4) to the "OFF" position
and remove the plug from the wall outlet.
5. Maximum grating time is 5 min. in continuous operation.
Assembly instructions for grater
• Remove the front cover (Fig. 1).
• Place and turn the grater body counter-clockwise so that it clicks firmly into place
(Fig. 2).
• Place the grated food container under the grater.
• Insert the plug into the wall outlet.
• Set the speed control button to position 5. Then place the food in the container and
push it into the container with the stamper.
• After use, switch off the appliance and unplug it.
• Press the grater locking button (see Fig. 1). Turn the grater clockwise and remove the
entire grater assembly (Fig. 3).
• Place back the front cover.
1. Fine vegetable grater
2. Coarse vegetable grater
3. Grater for thick slices
4. Grater for thin slices
5. Potato grater
1
RM7000 | RM7010 | RM7020 | RM7030 | RM7500 | RM7510
2 3
Release
button
Fig. 1
Fig. 2
Fig. 3
4 5
