17 Introduction
LED
5 White
LED
6 White
LED
7 White
LED
8 Red and
white
LED
devolo Magic 2 WiFi next
Flashing be- Meaning
haviour
Status 1: Status 1:
Flashes at This devolo Magic adapter is in pairing
intervals of mode and the system is searching for new
0.5 sec. devolo Magic adapters.
(on/off)
Status 2:
Status 2: Someone has triggered the "Identify device"
Flashes at in- function on the web interface or in the
tervals of 1 devolo Home Network App. This function
sec. (on/off) identifies the devolo Magic adapter being
sought.
Lights up stea- The devolo Magic connection does not have
dy any issues and the devolo Magic adapter is
ready to operate.
Flashes at in- The devolo Magic adapter is in standby mo-
tervals of de.***
0.1 sec.. on /
5 sec. off
Flashes at in- The devolo Magic adapter is carrying out a
tervals of firmware update.
0.5 sec. red/
0.5 sec. white
LED status display
(web interface*)
Cannot be disabled
Can be disabled
Can be disabled
Cannot be disabled
