This power tool is double insulated.All the
external parts are insulated from the mains
power supply. This makes it unnecessary for
this power tool to be earthed.
TECHNICAL DATA
Voltage
|230-240 V~
Frequency
|50 Hz
Power input
|500 W
No load speed
|300-3400/min
Saw stroke
|15 mm
Weight
|2.2 kg
Lpa (sound pressure)
|85.0 dB(A)
Lwa (sound power)
|98.0 dB(A)
Vibration
|11.133 m/s
2
Max.saw capacity in wood
|110 mm
Max.saw capacity in plastic pipe
|Ø125 mm
Max.saw capacity in steel
|3 mm
FEATURES
1 Upper grip
2 Handle
3 On/off switch
4 Safety switch
5 Sawblade holder and release opening
6 Speed regulation wheel
7 Blade for sawing wood
8 Blade for sawing metal
9 Jig saw/blade for sawing curves
10 Allen key
Fitting a Blade
• Remove the saw from the power supply.
• Loosen blade retention bolt (5) using the allen key supplied
(dia.2). Do not completely unscrew. Fit the blade as shown
and fully retighten the blade retention bolt.
Warning!
When turning the allen key to remove a blade, be very careful
not to catch your hand or fingers on the blade as the bolt
suddenly loosens under force (Best hand position shown dia.3).
Before use
• Make sure the items you want to cut are free from other
obstacles, cables, furniture etc.
• Always cut with the blade edge facing away from you - never
towards you!
• Never cut items close to your body.
4
GB
Using the saw
Your saw has a variable speed wheel 1 - 6 (6).
Move the dial from 1 (slow) up to your preferred speed. Only
alter the speed setting when the motor has stopped (dia.4).
To operate the motor press the safety switch (4) down and
depress the trigger (dia.5). Use the top grip (1) to guide the
cutting action.
You can move the saw backward and forward if required but do
not force it.
To stop the saw, simply take your finger off the trigger.
The smaller blade supplied is used to cut thin gauge metal
(max. 3mm) such as aluminium or copper. This blade is
attached in exactly the same way. Do not force the blade when
cutting through metal.
Cleaning
Remove the saw from the power supply.
Use only a soft slightly damp cloth to clean your saw.
Do not use general household cleaners as they may damage the
plastic casing.
Do not use petrol, paint thinners, or any other chemicals.
Do not use the saw if it has been exposed to water or any
other liquids.
EC Declaration of Conformity
We declare under our sole responsibility that this product
conforms with the following standards or standardised
documents:
98/37/CEE, 73/23/CEE, 93/68/CEE, 89/336/CEE
in accordance with regulations:
EN 50144-1, EN 50144-2-3, EN 55014-1, EN 55014-2,EN
61000-3-2, EN 61000-3-3
From 02-12-2003
ZWOLLE
W. Kamphof
Quality Department
It is our policy to continuously improve our products and we
therefore reserve the right to change the product specification
without prior notice.
Ferm BV, Zwolle, The Netherlands
