LED Indicator
7
The Multiload Pro has green, yellow and red LEDs to indicate the device's
operating status Consult the following table for the meaning of each
LED signal
Conditions
Mode select fault
Output voltage too low
Fan fault
Over temperature
Output over voltage
Output over current
Input over/under voltage /
Frequency
Constant current/voltage
Float stage
Battery over temperature
Charge Voltage Selection
8
The Multiload Pro can provide four battery charging voltages which may
be set using the switchs
SW1
0
1
1
0
*Multiply values by 2 for 24V mode!
Note: Only adjust the switches when the device is turned off!
Red
Blinking 0 5s
Solidly lit
Blinking 0 5s
Blinking 2s
Solidly lit
Solidly lit
Solidly lit
Off
Off
Off
SW2 Fast Values
1 12 2V
0 13 8V
1 14 2V
0 14 4V
ECTIVE Multiload Pro
Yellow Green
Blinking 0 5s Blinking 0 5s
Blinking 2s
Off
Off
Blinking 0 5s
Solidly lit
Off
Solidly lit Solidly lit
Blinking 2s Solidly lit
Blinking 2s
Float Values
12V
13 6V
13 6V
13 8V
27
Off
Off
Off
Off
Off
Off
Off
