Main Switch
1
Once the Multiload Pro has been properly installed and the batteries are
connected, use the switch to turn the device on Set the switch in the
appropriate position depending on whether you are charging a 12V or
24V battery The device will automatically begin operation according to
the source of the input voltage Flip the switch to the "OFF" position to
turn the device off
BTS Port
2
Connect a battery temperature (e g ECTIVE TS 1, sold separately)
sensor to this port to ensure proper charging of the batteries based
on their temperature Using a BTS will help extend battery life by
preventing overcharging in warm temperatures and undercharging in
cold environments
Ground Terminal
3
Connect the GND to the Ground Terminal using 8 AWG wire
Battery Connector
4
Connect the battery to the positive (+) battery terminal and the negative
(–) battery terminal Do not reverse the polarity!
