5.1 Mounting the push handle

Pos. Description
1 Push handle
2 Screws M4 (6 x)
Mount the push handle as follows:
1. Screw the push handle (Pos. 1) with the screws (Pos. 2) to the threads
(Pos. 3) provided on the product.
DANGER
Danger of falling or damage to the product!
The push handle (Pos. 1) is only used to push/pull the product.
• Never lift the product by the push handle!
1502872-02
Fig. 18: Mounting the push handle
Pos.
3
Tab. 21: Mounting the push handle
- 72 -
Description
Thread M4
EN
