Pos. Description
1 Push handle
2 Air outlet grille with
connection NW 63
3 Operating control
4 Filter housing
5 Connection for extraction
hose NW 45
6 Maintenance cover
7 Clamp fasteners
8 Vent
9 Vent with pre-filter mat
3.2 Distinguishing feature – W3/IFA certified
The product is manufactured in two versions:
• Version – non-IFA certified
• Version – IFA certified
1502872-02
Pos.
10
11
12
13
14
15
16
17
Tab. 19: Positions on the product
Fig. 17: Connections
- 64 -
Description
Rear wheel
Maintenance cover, dust
collection container
Name plate
Compressed air connection
(only for product with
cleaning)
Communication interface
Connection cable with plug
Cable holder
Tool tray with cup holder
(optional)
EN
