3.3. HORN ROTATION ( IS26T ONLY )
To rotate the horn of the model IS26T:
a) position the speaker safely on a level surface.
b) remove the front grille by unscrewing the four
screws in the upper and lower panels of the
speaker and the front screws.
c) Remove the grille and unscrew the four
screws securing the horn to the speaker.
d) rotate the horn through 90°, observing the
indications of the labels as described below,
and reassemble.
3.4. HORN REPL ACEMENT
Using accessory kit HK-15100WG or HK-6090, you can change the horn installed on the speaker as required.
Proceed as follows:
a) Position the speaker safely on a level surface.
b) Remove the front grille by unscrewing the four screws in the upper and lower panels of the speaker and
the front screws.
c) Remove the grille.
d) Unscrew the four screws securing the horn to the speaker.
e) Remove the horn.
f) Position the new horn following the indications below.
g) Fix the new element inside the speaker using the four screws provided.
h) Insert the grille in its location in the speaker.
i) Replace and tighten the four screws located on the upper and lower panels of the speaker and the front
screws.
