1. Illustrations and directives concerning use:

The operation of the digital receiver is simplified by the use of the "On Screen Displays",
which also serves to reduce the number of keys required on the remote control unit. All
functions are displayed on the screen, and can be operated with a few keys. Related
functions are combined in a "MENU". The function selected is highlighted in colour. The
"function keys" red, yellow, green and blue are indicated by colour bars in the bottom
line. These colour bars represent different functions in the various menus, which will be
activated by pressing the appropriate coloured key (multifunction key) on the remote
control. The "Function keys" are only active when a brief description is displayed in the
appropriate field.
On/standby Arrow keys
OK button
Slide the CONAX Smartcard (golden chip facing down and positio-
ned in direction of insertion) until it is firmly inserted in the card
reader.
Your unit bears the CE mark and meets all the necessary EU standards.
TechniSat and Digit HD4 CX are registered trademarks of
LED-Display
USB socket Smartcard reader
TechniSat Digital GmbH
4
