3.2 Connecting TV set with DVB receiver

TV can be connected to DVB receiver in three ways, depending on the different interfaces:
> Connect the receiver (HDMI output) and TV set (HDMI input) using an HDMI cable.
If your TV set is appropriately equipped it will automatically switch this over to the
HDMI input when the digital receiver is switched on.
> Use a component cable to connect the receiver (YUV) with the television set (YUV).
> Use a SCART cable to connect the receiver (SCART socket TV) with the television set
(SCART socket). If your television set is appropriately equipped, it will automatically
switch to AV, and thus to satellite operation, when the digital receiver is switched on.
4. Initial installations
When switching on the receiver for the first time, the starting window of the installation
assistant AutoInstall will be displayed. If you press the red function key you will be taken to the
previous step of the installation, thus giving you an opportunity to correct errors at any time.
In the following steps of the installation, you can then confirm the settings made by pressing
the green function key; you will then be taken to the next step of the installation procedure. If
the initial installation is not performed, or if it is aborted, the receiver will commence operation
with a standard pre-programmed procedure.
5. Operations
5.1 Switching on and of
> Press the On/Standby key either on the digital receiver or the remote control to
switch the receiver on.
> Press the same key again to switch the receiver of again.

5.2 Channel selection

We can select channels for diferent ways:
> Using the channel up/down keys.
> Use the channel up/down keys on the remote control or on the receiver to move up
or down the list one channel slot at a time.
> You may use the numeric keys to enter the desired channel number. For example:
1 for channel 1
1, then 4 for channel 14
2, then 3, then 4 for channel 234
When entering a channel number consisting of several digits, you have approx. 3 seconds after
pressing each number to complete the entry. If you wish to enter a number consisting of only
one or two digits, you can speed up the switching procedure by holding the key down on the
last digit.
> Using the channel list:
