6 THREE-SPEED OPERATION WITH REMOTE CONTROL CTRL-V3
The unit is operated using the supplied CTRL-V3 remote control:
f
i
j
a
b
Fig. 6.a CTRL-V3
FUNCTIONALITY
On/Off
Pressing the touch button the unit is activated/deactivated
Continuous operating speed
Speed I factory set is 135m
by acting on trimmer V1 as shown in Fig. 5.k.
Speed II factory set is 380m
adjusted by acting on trimmer V2 as shown in Fig. 5.k.
Speed III corresponds to the maximum speed and cannot be adjusted.
Humidistat operation
Regardless of the chosen operation or speed setting, when the humidity
threshold is reached, the fan speed increases by 15%. When the humidity
level falls below the threshold, the fan continues to run at the increased
speed for a pre-set period of time. The humidity threshold is adjustable
between 50% and 95% by means of a trimmer (Fig. 8.a).
BOOST operation
The unit will run at maximum speed for a fixed time period of 15'. At
the end of this time the unit returns to the previously set speed.
Motor anomaly
In the event of a motor malfunction, the red LED lights up. Contact
technical assistance.
Keypad lock
The CTRL-V3 buttons can be locked.
Keep the I and II buttons pressed contemporaneously for at least 5
seconds. Repeat this operation to unlock.
16
g
h
k
l
d
c
e
DESCRIPTION
/h @ 0Pa: if necessary it can be adjusted
3
/h @ 0Pa: if necessary it can be
3
a
To activate/deactivate the unit
To select speed V1
b
To select speed V2
c
To select maximum speed
d
e
To activate Boost function
Green Led: speed V1 selected
f
g
Green Led: speed V2 selected
Green Led: maximum speed selected
h
Blue Led: humidistat activation
i
Red Led: malfunction indication
j
Yellow Led: keyboard lock
k
Yellow Led: Boost function activation
l
TOUCH
BUTTON
I and II
(Keep pressed for
at least 5 seconds)
LED
ICON
COLOUR
-
I
I
green
II
II
green
III
III
green
-
blue
III
III green
and
yellow
-
red
yellow
-
