Capacitive Proximity Switches BCS R08RRE...
Installation options
Sensor installation without bracket
The sensor can be installed by screwing M3
screws through the fastening holes. Both reverse
installation and standard installation are possible.
Installation with bracket
The enclosed bracket features snap locks for a quick installation of the sensor. To insert or remove the
sensor, push down the two knurled tabbed surfaces on the bracket.
The distance flaps can be cut off if necessary.
6
Maximum tightening torque 0.2 Nm.
For tubes with small diameters, we recommend
installation using cable ties.
