Spare Parts List - Ferm RSM1014 Gebrauchsanweisung

No.
490049
490050
490051
490052
490053
490054
490100
490055
490056
490057
490058
490059
490060
490061
490036
490063
490064
490065
490012
407850
Ferm

Spare parts list

Description
Sole plate
Sole plate adjustment screws
Screw set housing
Housing
Screwset
Gearbox
LCD display + PCB
Rotation button
Speed switch
Spindle complete
Saw mechanism complete
Motor complete
Motor housing
Carbon brush set assy
Switch
Heat sink
Lock on lever
Battery contacts
Battery release box
Allen key 3mm
Position
1 + 2
3
4 + 15(9x) + 16(2x)
5 + 6 + 17 + 18 + 61 + 62
7 (4x) + 19(3x)
8 + 34(6x) + 35
10 TILL 12 + 20 + 21(3x)
13 + 14
22
23 TILL 26 + 40 TILL 45
27 TILL 34 + 37 + 38
45 TILL 51 + 55 TILL 57 + 24
52 TILL 54
49 + 55 + 56
58 + 59
60
64 + 65
66 + 67
68 TILL 72 + 74 +75
73
49
