Montageanleitung / mounting instruction
ECOLED III
ANSCHLÜSSE DIN LH /
2 1 2
1 GND 1 GND
2 Reverse 2 Tail
max. 5A max. 5A
CONNECTORS DIN LH
4
5
1
6
1 2 3
GND Tail LH Reverse DI LH
3
1
2
7
4 5 6 7
Stop Fog Tail RH
2 1 2
1 GND 1 GND
Tail
2 2 Tail
(SMCG)
max. 1A max. 5A
