Montageanleitung / mounting instruction
ECOLED III
ANSCHLÜSSE ASS2 LH /
1 2 1
1 GND 1 GND
2 Reverse 2 Tail
max. 5A max. 5A
CONNECTORS ASS2 LH
8
2
2
7
1/4 2 3
DI LH Fog GND
1/4
3
6
5
5 6 7 8
Tail RH Stop Tail LH Reverse
1 2 1
1 GND 1 GND
Tail
2 2 Tail
(SMCG)
max. 1A max. 5A
2
12
