Anschlüsse Ass2 Rh - Aspöck Systems ECOLED III Montageanleitung

Montageanleitung / mounting instruction
ECOLED III
ANSCHLÜSSE ASS2 RH /
1 2 1
1 GND 1 GND
Tail
2 Tail 2
(SMCG)
max. 5A max. 1A
CONNECTORS ASS2 RH
8
2
2
7
1/4 2 3
DI RH Fog GND
1/4
3
6
5
5 6 7 8
Tail RH Stop Tail LH Reverse
1 2 1
1 GND 1 GND
2 Tail 2 Reverse
max. 5A max. 5A
2
11
