Montageanleitung / mounting instruction
ECOLED III
ANSCHLÜSSE DIN RH /
2 1 2
1 GND 1 GND
Tail
2 Tail 2
(SMCG)
max. 5A max. 1A
CONNECTORS DIN RH
4
5
1
6
1 2 3
GND Tail RH Reverse DI RH
3
1
2
7
4 5 6 7
Stop Fog Tail LH
2 1 2
1 GND 1 GND
2 Tail 2 Reverse
max. 5A max. 5A
