Boya BY-M1 Pro Benutzerhandbuch Seite 8

Troubleshooting
Problem
The microphone dose not turn
on
The battery discharges too
quickly
Too much ambience noise is
being picked up
Specifications
Transducer
Polar pattern
Frequency range
Signal/Noise
Sensitivity
Output impedance
Battery type
Connector
Pad switch
Dimensions
Weight
Solution
The battery may be incorrectly oriented in the
battery compartment. Open the battery
compartment and make sure the battery is correctly
installed.
The battery may be exhausted. Replace it with a new
one. See the Specifications section for compatible
replacements.
The battery terminals are dirty. Open the battery
compartment and clean the terminals with a cotton
swab.
The microphone is being left on (in the Camera
position). Turn off the microphone by switching to
OFF to save battery when recording stopped.
You are using the microphone in extremely hot or
cold conditions which drains it quickly.
When there are too many background noise, switch
to -10dB to reduce unwanted background noise.
Electret condenser
Omni-directional
65 Hz ~18 kHz
78 dB SPL
-30 dB ± 3 dB /0 dB=1V/Pa, 1kHz
1000 Ohms or less
LR44 included /compatible with LR44, 357 and
SR44)
3.5 mm (1/8") 4-pole gold plug
0/-10dB
6.0m
58g
