7.1.1 MAIN Menu-1
MAIN Menu-1 Default
SHUTTER / AGC AUTO
LENS AUTO
EXT1
(w IR
LED)
DAY/NIGHT
AUTO
(w/o IR
LED)
PICT ADJUST –
WHITE BAL ATW
D-WDR OFF
BACKLIGHT OFF
NEXT
EXIT
SAVE ALL
Descriptions
Sets the parameters related to the shutter mode and AGC for AUTO and MANUAL
settings. See the details 7.2 SHUTTER/AGC menu.
Selects the lens type, AUTO or MANUAL. AUTO supports DC auto-iris lens only.
See 7.3 LENS menu for details.
Can set DAY/NIGHT to AUTO, COLOR, BW, EXT and EXT.
AUTO – Must be used only for a camera with NO IR LEDs.
Camera switches DAY from/to NIGHT automatically along with the
amount of light through the lens.
BURST, DELAY CNT, DAY –> NIGHT, NIGHT –> DAY can be set.
See DAY/NIGHT menu for details.
COLOR – DAY/NIGHT is disabled and forces to DAY mode only.
BW – DAY/NIGHT is disabled and forces to NIGHT mode only.
Camera switches its IR cut filter out and outputs BW video.
EXT1 – Must be used only for a camera equipped with IR LEDs.
DAY/NIGHT is switched by the external light sensor.
EXT2 – NEVER USE this mode.
Sets MIRROR, BRIGHTNESS, CONTRAST, SHARPNESS, HUE or GAIN.
See 7.5 PICT ADJUST menu for details.
Sets ATW, PUSH, USER, USER, ANTI CR, MANUAL or PUSH LOCK.
See 7.6 WHITE BAL menu for details.
Sets ON/OFF for enabling/disabling D-WDR (Digital Wide Dynamic Range)
compensation for the better dynamic range (D-WDR) of the image.
See 7.7 D-WDR menu for adjusting the dynamic ranges.
Selects BACKLIGHT mode out of OFF, HLC or BLC.
Areas and gains for HLC and BLC are factory preset and not user adjustable.
Moves to MAIN Menu
Exits the setup menu. To save the changes, move cursor to SAVE ALL and press
button before exiting the setup menu
Saves all parameters by pressing button when cursor is on SAVE ALL.
