M OU NT I NG TH E B L AD E S
Blade arm screw
• TIP: Blade bolt washers can be attached to each bolt prior to installing blades. Align the
juicers on the blades with the screw holes on the motor. Tighten all the screws once you
have hooked the blades. Before permanently fixing the screws, repeat this process with
the remaining ones.
AS SE MB LI N G THE CO NNECT I O N PANE L
Attach the connection plate to the bottom of the fan by inserting the heads of the fixing
screws into the holes intended for this. Drive in the screws and then secure them.
LE D PAN E L AN D D ECO R AT I VE SCRE E N
1
E NGL I SH
10
1
Lamp panel
Lamp panel
screw

CEILING FAN WITH LED LIGHT

Lamp panel
Pin
LED panel
2
2
