Bedienungsanleitung DC 3000
37 Pol Sub-D
1
20
2
21
3
22
4
23
5
24
6
25
7
26
8
27
9
28
10
29
11
30
12
31
13
32
14
33
15
34
16
35
17
36
18
37
19
type:
+24 V Out
+24 V Out
GND
GND
INPUT
START IN
INPUT
ERROR Extern IN
INPUT
Prog Bit 0 IN
INPUT
Prog Bit 1 IN
INPUT
Prog Bit 2 IN
INPUT
Prog Bit 3 IN
INPUT
Prog Bit 4 IN
INPUT
Prog Bit 5 IN
INPUT
REMOTE IN
GND
RESERVED
GND
RESERVED
GND
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
GND
OUTPUT
READY OUT
OUTPUT
BUSY OUT
OUTPUT
ERROR OUT
RESERVED
GND
RESERVED
RESERVED
RESERVED
RESERVED
VCC Reserved
VCC Reserved
VCC Reserved
RESERVED
17
