Deltaplus TC007 Bedienungsanleitung Seite 12

muddy or icy.
h) Prolonged use in salty environments (e.g. sea cliffs) may
affect the performance of the product.
i) Do not expose the device to significant heat or cold (see
work and stock temperature).
j) Avoid any contact with chemical reagents as they may affect
the performance of this product. Contact the producer if in
doubt.
k) This device is not tested for use in explosive atmospheres.
l) The descender device should never be left in place
(specifically o utdoors), e .g. a t a workstation, because of the
weathering d eterioration o f the rope.
FUNCTIONING PRINCIPLES
Figure 1: INSTALLATION OF THE ROPE
To install the descender on the rope, press the opening button
and simultaneously slide the housing sides apart. The working
end of the rope exits the device close to the axle around which
the housing sides rotate (consult the sketch on the housing for
help). Lead the rope around the cam so that the free end of the
rope exits the device between both camming elements. Slide
the housing sides back together. The device is only closed
properly once the opening button locks the top housing side
and is fully released. The TC007 used as a descender can
either be attached to a harness concordant with either EN 361,
EN 813 or EN 12277 (fig. 4/A – the operator slides with the
descender along the rope) or it can be fastened to an anchor
(fig. 4/B – the rope slides through the non-moving descender).
WARNING: If the rope is not inserted correctly the locking
mechanism does not work.
Figure 2: FUNCTIONAL PRINCIPLES
Figure 3: OPERATIONAL CHECK
• Check that the sides of the housing cannot be slid apart and
the closing button is fully released (the device is closed
correctly).
• Check whether the rope is inserted correctly (according to the
sketch on the housing).
• Before each use, carry out an operational check of the device
by test-loading it with your body weight while secured by other
