2.5.1 Connection diagram

Voltage heating elements 220 - 240 V.
Any kind of connection: the safety wire must be
connected to the
➢ For
220 - 240 V
earthed one-phase
connection.
➢ Bridges connect 1 - 2
1
- 3 terminals and
4 - 5 terminals.
➢ Protective earth to
➢ For
220 - 240 V earthed
three-phase
connection.
➢ Bridges connect 4 - 5
2
terminals, phases in
succession 1, 2 and 3,
Neutral to 4 - 5.
➢ Protective earth to
L1 = live wire
WARNING! Any kind of connection: the safety wire must be connected
to the PE terminal.
➢ Your domestic circuit must be equipped with an automatic circuit breaker.
➢ The appliance must be grounded.
➢ The technical data of your energy supply must meet the values on the rating
plate.
PE terminal.
400 /
N= Neutral terminal
X = power cord
~ ~
74
Recommended
type of
connection
lead.
H05VV-F3G
4 mm
H05VV-F5G
1.5 mm
PE= protective earth
terminal
2
2
