Electrical Connection (Connection: Oven And Hob) - Pkm BIC3 I GK IX5 Bedienungsanleitung

A
BBREVIATION
L
N
PE
➢ Your domestic circuit must be equipped with an automatic circuit breaker.
➢ The appliance must be grounded.
➢ The technical data of your energy supply must meet the values on the rating
plate.

2.5.2 Electrical connection (connection: oven and hob)

RIGHT CONNECTION
F
UNCTION
Live wire / mains
conductor
Neutral terminal
Protective earth
terminal
T
ERMINAL BLOCK
~
C
OLOUR
L 1 / L 2 / L 3
R
ED
N 1 / N 2
B
LUE
Y -
ELLOW GREEN
WRONG CONNECTION
~
77
C
ABLE
DIAMETER
≥ 1,5 mm 2
≥ 1,5 mm 2
≥ 1,5 mm 2
