a. Place the appliance on a stable and soft surface (use the packaging).
b. Do not exert any physical force to the control elements of the appliance.
c. Install the fixing brackets on the sides of the hob using the corresponding
screws: screw one end of the fixing brackets into the pre-drilled holes (as shown
in the fig. below).
A
B
C
D
3. Insert the hob into the installation opening and align it correctly. Push the hob
down carefully until the hob and the seal are in firm contact to the worktop (s.
fig. below).
The hob must be in the installation opening of the worktop properly and firmly.
Check the seal for perfect fit and overall cover.
H
OW TO INSTALL THE FIXING BRACKETS
H
~
S
CREW
B
RACKET
S
CREW HOLE
OUSING OF THE HOB
~
