NB3711
NRSW-Benutzerhandbuch - Version 4.6.0.100
Non-isolated 3-wire RS-232 Port Specification Option S
The non-isolated 3-wire RS-232 port has the following specification (bold characters show the default
configuration):
Funktion
Protocol
Baud rate
Data bits
Parity
Stop bits
Software flow control
Hardware flow control
Galvanic isolation to enclosure
Max. cable length
Cable shield
Tabelle 3.30.: Pin Assignments of RS-232 Port Signals (EP1 / EP2)
Spezifikation
3-wire RS-232: GND, TXD, RXD
300, 1 200, 2 400, 4 800, 9 600, 19 200, 38 400,
57 600, 115 200, 230 400, 460 800
7 bit, 8 bit
none, odd, even
1, 2
none, XON/XOFF
none
none
10 m
mandatory
Tabelle 3.29.: Non-isolated RS-232 Port Specification
EP Pins
Signal
1 / 5
GND
2 / 6
TxD
3 / 7
RxD
4 / 8
34
