NB3711
NRSW-Benutzerhandbuch - Version 4.6.0.100
Standard
802.11g
802.11n
802.11ac
Note: 802.11n and 802.11ac supports 2x2 MIMO
The WLAN antenna ports have the following specification:

Funktion

Max. allowed cable length
Max. allowed antenna gain
including cable attenuation
Min. distance between collocated radio
transmitter antennas
(Example: WLAN1 to MOB1)
Min. distance between people and an-
tenna
Connector type
1
Note: WLAN antennas with a higher amplification may be used with the NetModule router Ënhanced-RF-
Configurationßoftware license and the antenna gain and cable attenuation that have been correctly configured by certified
specialized personnel.
Frequencies
2.4 GHz
2.4/5 GHz
5 GHz
Tabelle 3.7.: IEEE 802.11 Standards
Spezifikation
30 m
3.0 dBi
20 cm
40 cm
TNC
Tabelle 3.8.: WLAN Antenna Port Specification
24
Bandwidth
20 MHz
20/40 MHz
20/40/80 MHz
1
Data Rate
54 Mbit/s
300 Mbit/s
866.7 Mbit/s
