Identify Button: Identification & Reset - OSRAM e:cue SYMPL Installationsanleitung

General device description
e:net
Error
Status +
Error
e:bus status
2.4 Identify button: Identification & Reset
The Identify button has two functions: to send an Identify message (A) and
to reset the Node (B).
(A) A short press during operation in online mode sends an Identify
message to the server. This helps to assign the Node in the Layout in
SYMPHOLIGHT.
(B) The Identify button can also be used to reset the device to factory state
or to stay in bootloader mode:
• Keep the Identify button pressed while powering up, Status and
Error light up at first. Bootloader mode is signaled by a fast blinking
Status LED. Release the button now. The device stays in bootloader
mode to download a new firmware.
To exit the bootloader mode, short press the Identify button again.
• Press the Identify button until Status and Error LEDs blink
10
Off: no link available.
On: link established.
Blinking: e:net traffic.
Off: no error detected.
On: If constantly lights in red, an error occurred. This
can be an internal error or malfunction of the device, or
an external error, e.g. a shortcut of interface
connections or alien power supply. Switch the device off
and on. If the error persists, check the wiring or contact
OSRAM Service.
The Status and Error LED blink simultaneously to
identify the SYMPL Node (enabled "Identify Interface
Mode" in SYMPHOLIGHT).
Off: no e:bus activity.
On: e:bus activity.
