6.3 Switching ON/OFF (Fig. 9)
To switch on:
Press the locking button (3) and the ON/OFF
switch (2) at the same time
•
Allow the saw blade to accelerate until it
reaches full speed. Then slowly move the saw
blade along the cutting line. Only exert gentle
pressure on the saw blade as you do so.
To switch off :
Release the locking button and ON/OFF switch
•
If you release the handle the equipment will
shut down automatically which means that it
cannot operate accidentally.
•
Ensure that you do not cover or block the ven-
tilation openings whilst working with the tool.
•
Do not slow down the saw blade after you
switch it off by pressing it sideways.
•
Important! Do not put down the machine until
the saw blade has reached a complete stand-
still.
Important. Carry out a trial cut in a piece
of waste wood
6.4 Changing the saw blade (Fig. 11-12)
Important. Always pull out the power plug
before doing any work on the circular saw!
Use only saw blades which comply with standard
EN 847-1 and are of the same type as the saw
blade supplied with this circular saw. Ask your
dealer for advice.
Use the saw blade key (13) supplied to change
the saw blade.
Attention! The hand-held circular saw must not
be operated with the saw blade key (13) inserted
in it.
•
Press the spindle lock (11).
•
Undo the screw to secure the saw blade (17)
using the saw blade key (13).
•
Push back and secure the moving swing
guard hood (19) using the lever for the swing
guard hood (20).
•
Remove the clamping flange (18) and the
saw blade (12) in a downwards direction.
•
The hand-held circular saw is supplied com-
Anl_TC_CS_1410_SPK9.indb 20 Anl_TC_CS_1410_SPK9.indb 20
GB
plete with two saw blade holder (22+23) for
saw blades with 16 mm and 30 mm saw bla-
de holes. The right saw blade holder needs
to be used according to the saw blade being
used.
•
For saw blades with 16mm saw blade hole:
Insert the 16mm blade holder (22)
•
For saw blades with 30mm saw blade hole:
Insert the 30mm blade holder (23)
•
Clean the flange and insert the new saw bla-
de. Pay attention to the running direction (see
arrow on the guard hood and saw blade)!
•
Tighten the screw to secure the saw blade
(17) and check that the blade runs true.
•
Before you press the On/Off switch, make
sure that the saw blade is correctly fitted and
that moving parts run smoothly and the clam-
ping screws are tightened securely.

7. Replacing the power cable

Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
