Eneo HDB-2080Z03IR Schnellinstallationsanleitung Seite 16

In case that HD-SDI Inputs are not supported in Monitor, please use HD-SDI Conver-
ter to connect HD-SDI cable with Monitor.
VIDEO SUB-OUT
connector
Technical specifications
Protection rating (IP / IK):
Temperature range (operation):
Power consumption:
Dimensions:
Weight:
16
IP68
-20°C ~ +50°C
10W
100mm x 107.8mm x 277mm
1.35kg
HD-SDI CABLE
AC24V/GND (Black
wire)
AC24V/DC12V (Red
wire)
RS485+
(White wire)
RS485- (Grey wire)
Joystick
