ⓐ Fixing screws for
sunshield (2x)
ⓑ IR LED
ⓒ Window
ⓓ Bracket foot
ⓔ Foot mount hole (4x)
ⓕ Wall mount bracket
ⓖ Sun shield
ⓗ Bracket Lock
ⓘ OSD cover

Product description and connections

ⓐ
ⓑ
ⓒ
ⓙ Hook for Easy Bracket
ⓚ Cable exits (5x)
ⓙ ⓚ
ⓛ Peg for Easy Bracket
ⓜ Wall mount hole (4x)
ⓝ Bracket foot fixing hole (4x)
ⓛ
ⓜ
ⓝ
the wall, ⓛ Peg for Easy bracket Hook must be
placed upwardly.
ⓓ
ⓖ
CAUTION:
Easy Bracket cannot be installed on
the ceiling. When it is installed on
ⓔ ⓕ
ⓘ ⓗ
