Assembly instructions
EN
Fig. 1.31
Push the top glass mounting rail from right to left (the side distance on
the left and right should be the same)
Fig. 1.33
Screws
4 x 60 mm
14
Fig. 1.34
Push the glass mounting rails down
(left and right)
Glass door fitting
Aluminium strip (fasten to
the floor with silicone)
Fig. 1.32
