PANORAMA SMALL parts list
Base frame
1 floor frame 4 x 8 x 151.5 cm
1 floor frame 4 x 8 x 206.5 cm
1 floor frame 4 x 8 x 150 cm
Wall element right side
1 wall element W1 51 x 194 cm
(Electrical element)
1 wall element W2 93.5 x 194 cm
Wall element rear side
1 wall element W3 93.5 x 194 cm
(Ventilation element)
1 wall element W4 102 x 194 cm
Wall element left side
1 wall element W5 93.5 x 194 cm
1 wall element W6 51 x 194 cm
(electrical element)
Corner posts
2 corner posts 184 x 7 x 4 cm
Mounting rails
2 mounting rails for glass element (left and right)
200.4 x 8.2 x 5.5 cm
1 mounting rail for glass element (top)
208.9 x 8.2 x 5.5 cm
2 cover strips for glass front (left and right)
193.4 x 7 x 2.5 cm
1 mounting rail for glass front (top)
213.9 x 7 x 2.5 cm
Roof
1 roof element 88 x 204.5 cm
1 roof element 59.5 x 204.5 cm
1 roof frame strip 4 x 2 x 151.5 cm
1 roof frame strip 4 x 2 x 206.5 cm
1 roof frame strip 4 x 2 x 150 cm
3 interior door cover strips 2.5 x 1 x 200 cm
2 interior door cover strips 2.5 x 1 x 150 cm
2 roof cover strips 201 x 4 x 1.2 cm
2 roof cover strips 158 x 4 x 1.2 cm
2 roof trim slats (left and right)
161.7 x 7 x 2.5 cm
The parts list can also be used as a claims sheet.
Glass front
1 glass element 195.2 x 69.4 x 0.8 cm
1 glass element 195.2 x 69.4 x 0.8 cm
with holes drilled for door hinges
1 glass element 191.5 x 59 x 0.8 cm
Cover strips
1 corner cover with groove 194 x 6.3 x 1.2 cm
1 corner cover with tongue 194 x 7.6 x 1.2 cm
1 corner cover with groove 194 x 5.3 x 1.2 cm
1 corner cover with tongue 194 x 6.4 x 1.2 cm
Interior fittings
1 ventilation shutter
1 bench 62 x 195 cm
1 bench 62 x 143 cm
1 bench 62 x 79.5 cm
2 foot sections 60 x 46.5 x 4 cm with struts
for lower bench
3 bench support slat 4 x 4 x 57 cm
1 bench screen 35 x 195 cm
2 mounting rails for bench screen 4 x 4 x 26 cm
1 back rest 186 x 26 x 5 cm
1 backrests 137 x 26 x 5 cm
1 heater protection grilles 65 x 58 x 2 cm
2 heater protection grilles 52 x 58 x 2 cm
1 lamp guard 38 x 32 cm
1 floor grid 70 x 53 cm
2 headrests 43.5 x 25 x 7 cm
Accessories
1 door handle set
1 door hinge set
2 aluminium strips 67.7 cm
1 stainless steel bench foot 84 x 6 cm
1 lamp without bulb
1 silicon cable 3 m 5 x 2.5 mm²
1 silicon cable 3 m 3 x 1.5 mm²
1 assembly material set
1 assembly instruction manual
