15-18 Photocell input (N.C.). If not used, leave the bridge 15-18 con-
nected.
15-19 Fault input (N.O.). Input for photocells provided with checking N.O.
contact (Fig. 3a).
15-20 Pedestrian pushbutton input (N.O.). Activation is carried out by motor
2; if the opening cycle has started (not from pedestrian function), the
pedestrian command has no effect.
21-22 Output for gate-open warning light output (N.O. contact (24Va.c./1A
max)) or alternatively 2nd radio channel (see paragraph 6 on "Con-
figuration").
23 Limit switch common terminal
24 Motor 2 opening limit switch for actuators with separate limit switches*
25 Motor 2 closing limit switch for actuators with separate limit switches*
26 Motor 1 opening limit switch for actuators with separate limit switches*
27 Motor 1 closing limit switch for actuators with separate limit switches*
29-30 Antenna input for radio-receiver plug-in board (29 signal–30 braid).
* When using the limit switches connected to terminals 5 and 8, leave the
jumpers at terminals 24-25-26-27.When using the limit switches connected to
terminals 24-25-26-27, provide jumpers between terminals 5-15 and 8-15.
5) PROGRAMMING
The control panel provided with a microprocessor is supplied with function
parameters preset by the manufacturer, suitable for standard installations.The
predefined parameters can be altered by means of either the incorporated
display programmer or UNIPRO.
In the case where programming is carried out by means of UNIPRO, care-
fully read the instructions relating to UNIPRO, and proceed in the following
way.
Connect the UNIPRO programmer to the control unit through the UNIFLAT
and UNIDA accessories (See fig. 4). The LIBRA-C-MA control unit does
not supply the UNIPRO programmer with power, and therefore requires an
appropriate supply unit.
Enter the "CONTROL UNITS"menu, and the "PARAMETERS"submenu, then
scroll the display screenfuls using the up/down arrows to set the numerical
values of the parameters listed below.
For the function logics, refer to the "LOGIC" submenu.
In the case where programming is carried out by means of the incorporated
programmer, refer to Fig. A and B and to the paragraph on "Configuration".

6) CONFIGURATION

The display programmer is used to set all the LIBRA-C-MA control panel
functions.
The programmer is provided with three pushbuttons for menu scrolling and
function parameter configuration:
+ menu scrolling/value increment key
- menu scrolling/value reduction key
OK Enter (confirm) key
The simultaneous pressure of the + and - keys is used to exit the active
menu and move to the preceding menu.
The modifications made are only set if the OK key is subsequently pressed.
When the OK key is pressed for the first time, the programming mode is
entered.
The following pieces of information appear on the display at first:
- Control unit software version
- Number of total manoeuvres carried out (the value is expressed in
thousands, therefore the display constantly shows 0000 during the first
thousand manoeuvres)
- Number of manoeuvres carried out since the latest maintenance opera-
tion (the value is expressed in thousands, therefore the display constantly
shows 0000 during the first thousand manoeuvres)
- Number of memorised radio control devices.
When the OK key is pressed during the initial presentation phase, the first
menu can be accessed directly.
Here follows a list of the main menus and the respective submenus available.
The predefined parameter is shown between square brackets [ 0 ].
The writing appearing on the display is indicated between round brackets.
Refer to Figures A and B for the configuration procedure.
6.1) PARAMETER MENU (PARAm)
- Automatic Closing Time (TCA) [ 10s ]
Set the numerical value of the automatic closing time from 3 to 120
seconds.
- Motor 1 torque (Mot1 torque) [ 50% ]
(UNIPRO ⇒ Advanced parameters ⇒ address 3)
Set the numerical value of the motor 1 torque between 1% and 99%.
- Motor 2 torque (Mot 2 torque) [ 50% ]
(UNIPRO ⇒ Advanced parameters ⇒ address 4)
Set the numerical value of the motor 2 torque between 1% and 99%.
- Motor 1 slow-down torque (m1 t slow) [ 45% ]
(UNIPRO ⇒ Advanced parameters ⇒ address 8)
Set the numerical value for slow-down torque of motor 1 between 1%
and 99%.
INSTALLATION MANUAL
- Motor 2 slow-down torque (m2 t slow) [ 45% ]
(UNIPRO ⇒ Advanced parameters ⇒ address 9)
Set the numerical value for slow-down torque of motor 2 between 1%
and 99%.
NOTE: In case of obstacle detection, the Ampere-stop function halts
the leaf movement, reverses its motion for 1 sec. and then halts in
the STOP status.
WARNING: Check that the impact force value measured at
the points established by the EN 12445 standard is lower than
that specified in the EN 12453 standard.
Incorrect sensitivity setting can cause injuries to persons or
animals, or damage to things.
- Opening delay time (open delay time) [ 1s ]
Set the opening delay time for motor 1 relative to motor 2, between 1 and
10 seconds.
- Closing delay time (cls delay time) [ 1s ]
Set the closing delay time for motor 2 relative to motor 1, between 1 and
25 seconds.
- Motor 1 fast time (m1 fast time) [ 15s ]
(UNIPRO ⇒ Advanced parameters ⇒ address 6)
Set the time to normal speed (not slowed down), ranging from 1 to 30
seconds.
are carried out from a different point, they will become effective as from
the subsequent opening manoeuvre.
- Motor 2 fast time (m2 fast time) [ 15s ]
(UNIPRO ⇒ Advanced parameters ⇒ address 7)
Set the time to normal speed (not slowed down), ranging from 1 to 30
seconds.
are carried out from a different point, they will become effective as from
the subsequent opening manoeuvre.
Note: The slow-down time, on closing and on opening, is obtained by
timing one manoeuvre and setting a minimum value for this parameter.
If, for example, one manoeuvre lasts 25 seconds, a setting of "normal
speed time" to 20s will produce a slow-down time of 5s both on closing
and on opening.
- Slow-down speed (slov speed) [ 50% ]
(UNIPRO ⇒ Advanced parameters ⇒ address 5)
Set the slow-down speed:
Sets the slow-down speed percentage between 0% and 99% of normal
speed.
0 – slow-down disabled (always fast).
- Zone (zone) [ 0 ]
Set the zone number between a minimum value of 0 and a maximum
value of 127. See paragraph 7 on "Serial connection".
6.2) LOGIC MENU (logic. )
- TCA (TCA) [ OFF ]
ON :Activates automatic closing
OFF:Excludes automatic closing
- 3 Steps (3 step) [ OFF ]
ON: Enables 3-step logic. A Start impulse has the following effects:
door closed: ................................................................................opens
on opening: .................................stops and enters TCA (if configured)
door open: ................................................................................. closes
on closing:...............................................................stops and reopens
OFF:Enables 4-step logic. A Start impulse has the following effects:
door closed: ................................................................................opens
on opening: .................................stops and enters TCA (if configured)
door open: ................................................................................. closes
on closing:...................................stops and does not enter TCA (stop)
after stopping: .............................................................................opens
- Impulse lock (ibl open) [ OFF ]
ON : The Start impulse has no effect during the opening phase.
OFF:The Start impulse becomes effective during the opening or closing phase.
- Rapid closing (fast cls) [ OFF ]
ON: Closes the gate after 3 seconds from photocell disengagement
before waiting for the end of the TCA set.
OFF:Command not entered.
- Photocells on opening (photc. open) [ OFF ]
(UNIPRO ⇒ Advanced logics ⇒ address 14)
ON: In case of obscuring, this excludes photocell operation on opening.
During the closing phase, it immediately reverses the motion.
OFF:In case of obscuring, the photocells are active both on opening and on
closing.When a photocell is obscured on closing, it reverses the motion
only after the photocell is disengaged.
- Photocell test (test phot) [ OFF ]
ON: Activates photocell check
OFF:Deactivates photocell check
If this setting is not activated (OFF), it inhibits the photocell checking
function, allowing connection of devices not provided with additional
checking contact.
Carry out the settings from the gate-closed position; if settings
Carry out the settings from the gate-closed position; if settings
