Clearaudio Master Reference Bedienungsanleitung Seite 25

Maximum Solution
Bedienungsanleitung/USER MANUAL
Place now the three belts, one on each pulley of the motors. For the first belt use the Motor
plugged into the APG (the power supply) at the number one. Then use for this motor the first
therefore cutted diameter in the pulley. When you place the second belt, use the motor
which is connected as the number two into the APG and turn the belt around the second
(middle ) diameter of the pulley. For the third belt use the last motor (connected as number
three into the APG) and the third (upper) diameter of the pulley.
1
2
3
The following adjustment is very important:
should the air bubble in the level gauge not be in the black circle (see at the blow up), please
ensure then that your underground so will be according aligned. Only if the turntable will be
aligned you will receive the optimum on sound.
Seite/Page 25 © clearaudio electronic GmbH 2007
