AquaForte IH30 Gebrauchs- Und Installationsanleitung Seite 8

5.2 Startup:
When the power is switched on, the screen will be fully light for 5 seconds, the software
version will be displayed, and then it will enter the normal working state. When the screen is
locked, only the button
other buttons will all light up. The screen will automatically lock up when there is no operation
for more than 1 minute and the brightness of the screen is reduced by 1/3 of the normal display.
Short press to wake up the screen and observe the relevant operating parameters.
5.3 Self-priming
When the pump starts for the first time, the system performs the self-priming procedure to
analyze the flow range of the pipeline system in actual installation. The running capacity will go
up from 30% to 100% by 5% each step, and run for 180 seconds. (The period could be set
from 180s to 900s). This first-time self-priming is mandatory and only takes effect after the first
installation or factory reset. It will not start again when the pump is turned on again. After the
first-time self-priming, pump will automatically redefine the adjustable range of the flow range
(the default flow range of this pump is 5-30 m³/h), after the first-time self-priming, the range
may be redefined to 7-28 m³/h, user still could set the flow rate from 5 to 30 m³/h, 3 seconds
after the setting is completed, the flow rate will be automatically adjusted to the actual
adjustable maximum or minimum value, namely 7-28m³/h.
5.4 Backwash
User can start the backwash or fast re-circulation in any running state by pressing
Time
Running capacity
If backwash is completed or disabled, press and hold
to the normal operating state before backwash.
6
will light up; Press and hold
Default Setting range
180s
Press
seconds for each step
100% 80~100%, enter the parameter setting (see 5.8)
for more than 3 seconds,
or to adjust from 0 to 900s with 30
for 3 seconds, the pump will return
.
