Optidew 501 Analysator zur Wandmontage – IP54
CHANGES TO WIRING
XXXX 25/05/17
N
COMPONENT CHANGES
XXXX 15/05/17
M
XXXX 27/04/17 MODIFIED FOLLOWING FIRST BUILD
L
FIRST DRAFT
XXXX 02/02/17
K
DATE
REV ECN No.
Michell Instruments
240.0mm 9.449"
260.0mm 10.236"
220.0mm 8.661"
BRM
BRM
BRM
RLS
DESCRIPTION APPROVED
CREATED
THIS DOCUMENT IS THE PROPERTY OF MICHELL
INSTRUMENTS LTD. AND MUST NOT BE COPIED
NOR DISCLOSED TO A THIRD PARTY WITHOUT
THE CONSENT OF MICHELL INSTRUMENTS.
MICHELL INSTRUMENTS LTD. 20/07/2016 F0150
ANHANG D
MATERIAL: See BoM
TOLERANCES & DIMENSIONS DRAWING TITLE:
3rd ANGLE 0 DEC. PLACE: ± 0.5
PROJECTION 1 DEC. PLACE: ± 0.2
Analyzer Assembly - O
2 DEC. PLACE: ± 0.1
HOLES Ø:± 0.1
ANGLES:± 0.5°
SCALE: NTS DRAWING UNITS: mm PROJECT:
DIMEN
(INCHE
7544
65
