FUNCTION, METHOD OF OPERATION

3.1 METHOD OF OPERATION
• electrochemically pickling and cleaning
• etching electrochemically
When pickling/cleaning the oxyd layer of the material will be removed
by electrochemical effect in a non toxic and environment-friendly way.
The surface of the stainless steel will be passivated simultaneously.
When electro - polishing, material is removed from the surface of the
workpiece by specific electrolytes used in conjunction with an external
DC source.
The material set free by the electrolyte is non - polluting and follows under
flattening conditions. In contrast to mechanical removal processes, flatte-
ning by electro - polishing begins in the micro range and includes, during
longer polishing periods, larger structures which are rounded and flattened
off on their top surface. During electro - polishing, two different mechanisms
work simultaneously, one flattens the upper surface in the micro range and
the other achieves fine deburring in the macro range.

3.2 OPERATING AND DISPLAY ELEMENTS

3.2.1 Rear side

A
Safety cut-out furse 0,5 Amp, for the marking function
B Main switch ON/OUT
